D E S I G N :
• Execellent chipflow, lower heat retention and increased
tool rigidity are provided by the 3 flute, low helix design
• Special Chipbreakers for Phenolic reduce cutting
pressure and noise levels
• Excellent chipflow and lower heat retention are
provided by the 3 flute design with Phenolic
Chipbreakers
• Submicron, corrosion resistant, extended life carbide
provides increased durability and resistance to resin
build-up
• 10º Helix design with plunging capability
A P P L I C AT I O N :
• Specifically designed to provide a excellent finish
and reduced noise levels when cutting Phenolic
• Faster feed rates at low spindle speeds
• 3 flute design allows for two cutting edges to be
engaged at all times, providing greater stability and
reducing run-out
• Improved cutting edge life when cutting Phenolic
• Downward cutting action helps hold down material
• For improved dust extraction use with an
Aerotech (page FC21)
