DESIGN:
- Superior surface finish is produced by the 3 precision ground cutting edges.
- Good chipflow and lower heat retention are provided by the 3 flute design.
- Submicron, corrosion resistant, extended life carbide provides increased durability and resistance to resin build-up.
- 30º Helix design with plunging capability.
APPLICATION:
- Commonly used for rebates, dadoes/grooving and pocketing operations on raw panels, one side laminated with face down or solid wood.
- Excellent finish on hardwoods, softwoods, laminated panels, MDF, chipboard, plywood and solid surface materials.
- Faster feed rates at low spindle speeds.
- 3 Flute design allows for two cutting edges to be engaged at all times, providing greater stabilityand reducing run-out.
- Incresed number of bite marks per inch reduces chip size and provides a smooth finish on the core of plywood and particleborards, especially important when edge-banding wihtout pre-milling operations.
- Eliminates chipping, fuzzing and tear out along the bottom face of the board.
- Upcut spiral improves chip ejection from the cutting path.
- For improved dust extraction use with an Aerotech (Page FC21)
FOR A PRICE, RING 01204 701000 !!
